Clean socks!

A couple of days ago, I observed over the course of a few hours Monte coming in from his shop project du jour, going into the laundry room, swearing, and then going back out to the shop. This happened at least three times. I finally asked him what was up. He said he was just trying to do a load of laundry because he needed a clean pair of socks. But the washing machine wasn’t cooperating. Every time he came in the machine had stopped, unlocked the door and the laundry inside was drenched.

Having fixed one of our washing machine problems a little over a year ago myself (a leaking rubber door gasket), I decided to try and figure out what was wrong this time.

The symptoms:

  • the wash cycle would not complete
  • it would start filling the tub, putting way more water in than I have ever noticed before, up to about 6″ up from the bottom of the door window.
  • at 45 minutes left in the wash cycle, it would stop filling, unlock the door, and blink the start/pause light
  • a 12 minute drain and spin cycle would sometimes work to drain the tub. Sometimes not.

After doing some research online, and messing around with the washer for a bit, I thought we had at least 2 problems:

  • the drain pump, which empties the tub and sends the water out the drain hose into the wall, was not working consistently. I took that out and Monte hooked it up in the shop to a switch, and sure enough, it would only turn on about 2 out of 10 tries.
  • the water level switch hose (a rubber 3/8″ hose) had a hole in it, which prevented the fill computer from correctly detecting the level of the water in the tub. Wear on that hose can happen over time from abrasion against the side of the washer tub and housing.

The website AppliancePartsPros.com is great resource for how-to videos, and also to follow discussion threads from other DIYers.

Our washing machine is a 12-year old GE Model WCVH6800J1WW. The 2 parts we needed were the drain pump (part #WH23X10028), and water level switch hose (part #WH41X10129). I ordered certified GE OEM replacement parts. The fix was easy, requiring only a phillips screwdriver and some pliers.

The two videos I watched to understand how to replace the parts I ordered were:

The first load just finished, and we finally have clean socks!

From leaky to squeaky clean.

Several months ago, I noticed water leaking from our 10-year old GE front-load washing machine while doing a load of laundry.  Upon inspection, I saw that a little piece of the rubber seal between the drum and the door had been torn away.

IMG_0172

For a while, a temporary repair involving tape worked.  But the leak returned and eventually got worse.

After a little internet research, I found and ordered a replacement part – a new rubber door gasket – and found a couple of videos walking through how to replace it step by step.    I suggest watching more than one, as each one highlights slightly different things.  These are the 2 videos I found.   I decided to give it a shot.

The part came in last week, so today was the day to install it!   The videos are only about 15 minutes long.   My total elapsed repair time was around 3 hours, though, which included collecting the tools I needed, moving the washer out to where I could work on it, cleaning everything as I went, and playing/pausing both videos as I proceeded from one step to the next.

The patient, with new door gasket sitting on top of the machine:

IMG_0171

While the videos say the repair is an easy one, it does require you to disassemble much of the machine, or at least more than I thought would fall into the “easy” category.

IMG_0174

New door gasket part-way installed!IMG_0176

I think it went pretty much as the videos showed.  Removing and reattaching the second clamp was not as easy as the videos made it look, but I went very, very slowly and it eventually worked out fine.  I’m doing the first post-repair load of laundry as I write this, and I don’t see as much as a drop of water on the floor.  Thank God.

The machine is fixed, it’s clean inside and out, and I finally leveled the washer after ten years of having it wobble a bit.  Bonus!





Whatever works.

One of the salon cushions on our Catalina 320 tore along a center seam. I tried mending it once and it just tore again, as the fabric had significantly weakened along the seam. I think the material is Ultrafabric Brisa Original (from around 2005).  I haven’t been able to find a color match yet. It’s just as well, though, as the fabric runs around $65/yard. I’m not ready to reupholster the entire set of salon cushions yet. Soooo, what can I use for a temporary fix?

I decided to repurpose a length of Tear-Aid Type-A tape that I originally got to patch a few holes in our Sunbrella bimini skin. It should adhere well to Brisa’s polyester and rayon backing. It’s not supposed to be sewn-through, but I don’t need a waterproof seal. I simply want to use it to patch along the back-side of the rip and to strengthen and reinforce the area around the tear so I can stitch a new seam through it, about 1/4″ in from the tear.

So I gave it a shot… and I’m happy with the repair.   Now I just need to wait and see how long it holds up.  Fingers crossed!

Before:



And after…

If you’re interested, here’s a few pics as I tried the fix.

I removed the cover from the inner cushion pieces, and ripped out the old seam on all 3 pieces of fabric involved in the seam.  The alcohol is to clean the Brisa fabric backing, where I want to apply the Tear-Aid.  The hair dryer is to help me flatten out the old folded seam allowance, and also to help dry the backing after I cleaned it.

Both pieces of Brisa are torn along the old seam.  I’ll need to patch both pieces in a similar fashion before trying to sew a new seam.

Tear-Aid says to clean the application area with alcohol and let dry.  As I cleaned the fabric with alcohol, I saw that the backing material was rotted away in places.   So I removed all the non-adhered backing along the tear.  Not sure how it got in this condition.  Maybe something caustic spilled here and weakened the fabric.  Or maybe 15 years is all you can get out of Brisa.

After cleaning and drying the pieces of Brisa, I used scotch tape on the right side (outside) of the tear to hold the edges of the tear together, temporarily.  I’ll remove it after I apply the Tear-Aid to the wrong side (inside) of the torn fabric.

I cut a length of Tear-Aid Type A tape and applied it on the backing-side of the Brisa fabric along the tears.   Tear-Aid recommends leaving an inch of patch around any torn area, but I didn’t have that much of material along the old seam allowance, so I used a smaller piece than they’d probably recommend.

img_9434

I removed the scotch tape from the right-side of the pieces of Brisa, and clipped the right-sides of Brisa together to prepare for stitching the new seam.  This time I’ll sew THROUGH the newly applied Tear-Aid, approx 1/4″ in from the tear along the old seam.

Stitching the seam was a bit challenging, as the adhesive from the patch gummed up the needle every 6 inches or so.  But, as long as I cleaned the needle each time with alcohol, it stitched pretty well.  I used a ballpoint (recommended for Brisa) needle, size 16, and V-69 poly thread, and I also found I had to lower my top thread tension.

There you have it.
